TopPack XPress
Plastic Tube Container TopPack XPress
High quality single piece packaging with XPress shankholding system. Ideal for precision shank tools such as solid carbide cutters and drills
- XPress plug design for simple and secure loading/removal of tool
- diagonally arranged clamping webs in the mounting base ensure perfect hold
- user-friendly function ensures easier and safer handling of sensitive and sharp-edged cutting tools
Product features TopPack XPress
The patented XPress shank clamping of TopPack XPress sets new standards in terms of user-friendliness and optimum holding force. As the transparent tube is fitted to the base plug, the diagonal clamping ribs are pressed hard against the tool and ensures secure shank holding. The shank remains loosely held during loading and removal of sensitive and sharp-edged cutting tools, resulting in easier and safer handling during the packaging process.
- XPress plug design for simple and secure loading/removal of tool
- diagonally arranged clamping webs in the mounting base ensure perfect hold
- user-friendly function ensures easier and safer handling of sensitive and sharp-edged cutting tools
- grooves in side of plug assist easy opening/closing
- used in conjunction with end caps increases tool holding and gives extra protection of delicate tools
- outers click securely into place with ratchet mechanism
- durable and reusable
- sturdy, oil, and moisture resistant
- For information on the compatibility between the outer part and the base plug and the resulting usable length, please refer to the last page of the data sheet
Available in the following materials
- outer part: Polypropylene (PP)
- base plug: Polyethylene (PE)
Available in the following variants
- outer part in transparent
- base plug and adapter in various attractive standard colors
- outer parts and base plugs are packed separately in individual cartons
Delivery program
| Image | Name | Actions | ||
|---|---|---|---|---|
|
TKA 13-3/4 Cap blue 01 LDPE 04
Material number: 114132 Packaging unit: 1000 Minimum order quantity: 1000 Availability: On stock |
Color: blue 01 Availability: On stock | Material: LDPE 04 Type of part: Adaptor cap Suitable for: TPK Ø 13 | |
|
|
TKA 13-6/4 Cap blue 01 LDPE 04
Material number: 114146 Packaging unit: 1000 Minimum order quantity: 1000 Availability: On stock |
Color: blue 01 Availability: On stock | Material: LDPE 04 Type of part: Adaptor cap Suitable for: TPK Ø 13 | |
|
|
TKA 18-8/4 Cap blue 01 LDPE 04
Material number: 114680 Packaging unit: 1000 Minimum order quantity: 1000 Availability: On stock |
Color: blue 01 Availability: On stock | Material: LDPE 04 Type of part: Adaptor cap Suitable for: TPKØ 18 | |
|
|
TKA 20-10/4 Cap blue 01 LDPE 04
Material number: 114743 Packaging unit: 500 Minimum order quantity: 500 Availability: On stock |
Color: blue 01 Availability: On stock | Material: LDPE 04 Type of part: Adaptor cap Suitable for: TPK Ø 20 | |
|
|
TKA 26-16/4 Cap blue 01 LDPE 04
Material number: 114816 Packaging unit: 300 Minimum order quantity: 300 Availability: On stock |
Color: blue 01 Availability: On stock | Material: LDPE 04 Type of part: Adaptor cap Suitable for: TPK Ø 26 | |
|
|
TKA 32-20/4 Cap blue 01 LDPE 04
Material number: 114829 Packaging unit: 300 Minimum order quantity: 300 Availability: On stock |
Color: blue 01 Availability: On stock | Material: LDPE 04 Type of part: Adaptor cap Suitable for: TPK Ø 32 | |
|
|
TKA 8-3/4 Cap blue 01 LDPE 04
Material number: 114661 Packaging unit: 1000 Minimum order quantity: 1000 Availability: On stock |
Color: blue 01 Availability: On stock | Material: LDPE 04 Type of part: Adaptor cap Suitable for: TPK Ø 8 | |
|
TPKXP 13x25-1/2"/1 I blue 01 LDPE 04
Material number: 56486 Packaging unit: 1000 Minimum order quantity: 1000 Availability: On stock |
Color: blue 01 Inner diameter (mm): 13.00 Inner length (mm): 25.00 Shank diam. (mm): 12.70 Availability: On stock | Material: LDPE 04 Type of part: Inner part | |
|
|
TPKXP 13x25-10/1 I blue 01 LDPE 04
Material number: 56496 Packaging unit: 1000 Minimum order quantity: 1000 Availability: On stock |
Color: blue 01 Inner diameter (mm): 13.00 Inner length (mm): 25.00 Shank diam. (mm): 10.00 Availability: On stock | Material: LDPE 04 Type of part: Inner part | |
|
|
TPKXP 13x25-12/1 I blue 01 LDPE 04
Material number: 56497 Packaging unit: 1000 Minimum order quantity: 1000 Availability: On stock |
Color: blue 01 Inner diameter (mm): 13.00 Inner length (mm): 25.00 Shank diam. (mm): 12.00 Availability: On stock | Material: LDPE 04 Type of part: Inner part | |
|
|
TPKXP 13x25-3/8"/1 I blue 01 LDPE 04
Material number: 56489 Packaging unit: 1000 Minimum order quantity: 1000 Availability: On stock |
Color: blue 01 Inner diameter (mm): 13.00 Inner length (mm): 25.00 Shank diam. (mm): 9.53 Availability: On stock | Material: LDPE 04 Type of part: Inner part | |
|
|
TPKXP 13x25-4/1 I blue 01 LDPE 04
Material number: 56490 Packaging unit: 1000 Minimum order quantity: 1000 Availability: On stock |
Color: blue 01 Inner diameter (mm): 13.00 Inner length (mm): 25.00 Shank diam. (mm): 4.00 Availability: On stock | Material: LDPE 04 Type of part: Inner part | |
|
|
TPKXP 13x25-6/1 I blue 01 LDPE 04
Material number: 56492 Packaging unit: 1000 Minimum order quantity: 1000 Availability: On stock |
Color: blue 01 Inner diameter (mm): 13.00 Inner length (mm): 25.00 Shank diam. (mm): 6.00 Availability: On stock | Material: LDPE 04 Type of part: Inner part | |
|
|
TPKXP 13x25-8/1 I blue 01 LDPE 04
Material number: 56494 Packaging unit: 1000 Minimum order quantity: 1000 Availability: On stock |
Color: blue 01 Inner diameter (mm): 13.00 Inner length (mm): 25.00 Shank diam. (mm): 8.00 Availability: On stock | Material: LDPE 04 Type of part: Inner part | |
|
|
TPKXP 18x34-12/1 I blue 01 LDPE 04
Material number: 64427 Packaging unit: 250 Minimum order quantity: 250 Availability: On stock |
Color: blue 01 Inner diameter (mm): 18.00 Inner length (mm): 34.00 Shank diam. (mm): 12.00 Availability: On stock | Material: LDPE 04 Type of part: Inner part | |
|
|
TPKXP 18x34-14/1 I blue 01 LDPE 04
Material number: 56500 Packaging unit: 250 Minimum order quantity: 250 Availability: On stock |
Color: blue 01 Inner diameter (mm): 18.00 Inner length (mm): 34.00 Shank diam. (mm): 14.00 Availability: On stock | Material: LDPE 04 Type of part: Inner part | |
|
|
TPKXP 18x34-16/1 I blue 01 LDPE 04
Material number: 56501 Packaging unit: 250 Minimum order quantity: 250 Availability: On stock |
Color: blue 01 Inner diameter (mm): 18.00 Inner length (mm): 34.00 Shank diam. (mm): 16.00 Availability: On stock | Material: LDPE 04 Type of part: Inner part | |
|
|
TPKXP 20x40-18/1 I blue 01 LDPE 04
Material number: 56504 Packaging unit: 250 Minimum order quantity: 250 Availability: On stock |
Color: blue 01 Inner diameter (mm): 20.00 Inner length (mm): 40.00 Shank diam. (mm): 18.00 Availability: On stock | Material: LDPE 04 Type of part: Inner part | |
|
|
TPKXP 20x40-20/1 I blue 01 LDPE 04
Material number: 56505 Packaging unit: 250 Minimum order quantity: 250 Availability: On stock |
Color: blue 01 Inner diameter (mm): 20.00 Inner length (mm): 40.00 Shank diam. (mm): 20.00 Availability: On stock | Material: LDPE 04 Type of part: Inner part | |
|
|
TPKXP 20x40-3/4"/1 I blue 01 LDPE 04
Material number: 56503 Packaging unit: 250 Minimum order quantity: 250 Availability: On stock |
Color: blue 01 Inner diameter (mm): 20.00 Inner length (mm): 40.00 Shank diam. (mm): 19.05 Availability: On stock | Material: LDPE 04 Type of part: Inner part | |
|
|
TPKXP 8x18-1/4"/1 I blue 01 LDPE 04
Material number: 56477 Packaging unit: 1000 Minimum order quantity: 1000 Availability: On stock |
Color: blue 01 Inner diameter (mm): 8.00 Inner length (mm): 18.00 Shank diam. (mm): 6.35 Availability: On stock | Material: LDPE 04 Type of part: Inner part | |
|
|
TPKXP 8x18-1/8"/1 I blue 01 LDPE 04
Material number: 56478 Packaging unit: 1000 Minimum order quantity: 1000 Availability: On stock |
Color: blue 01 Inner diameter (mm): 8.00 Inner length (mm): 18.00 Shank diam. (mm): 3.18 Availability: On stock | Material: LDPE 04 Type of part: Inner part | |
|
|
TPKXP 8x18-2.35/1 I blue 01 LDPE 04
Material number: 56484 Packaging unit: 1000 Minimum order quantity: 1000 Availability: On stock |
Color: blue 01 Inner diameter (mm): 8.00 Inner length (mm): 18.00 Shank diam. (mm): 2.35 Availability: On stock | Material: LDPE 04 Type of part: Inner part | |
|
|
TPKXP 8x18-3/1 I blue 01 LDPE 04
Material number: 56479 Packaging unit: 1000 Minimum order quantity: 1000 Availability: On stock |
Color: blue 01 Inner diameter (mm): 8.00 Inner length (mm): 18.00 Shank diam. (mm): 3.00 Availability: On stock | Material: LDPE 04 Type of part: Inner part | |
|
|
TPKXP 8x18-4/1 I blue 01 LDPE 04
Material number: 56480 Packaging unit: 1000 Minimum order quantity: 1000 Availability: On stock |
Color: blue 01 Inner diameter (mm): 8.00 Inner length (mm): 18.00 Shank diam. (mm): 4.00 Availability: On stock | Material: LDPE 04 Type of part: Inner part | |
|
|
TPKXP 8x18-5/1 I blue 01 LDPE 04
Material number: 56481 Packaging unit: 1000 Minimum order quantity: 1000 Availability: On stock |
Color: blue 01 Inner diameter (mm): 8.00 Inner length (mm): 18.00 Shank diam. (mm): 5.00 Availability: On stock | Material: LDPE 04 Type of part: Inner part | |
|
|
TPKXP 8x18-6/1 I blue 01 LDPE 04
Material number: 56482 Packaging unit: 1000 Minimum order quantity: 1000 Availability: On stock |
Color: blue 01 Inner diameter (mm): 8.00 Inner length (mm): 18.00 Shank diam. (mm): 6.00 Availability: On stock | Material: LDPE 04 Type of part: Inner part | |
|
|
TPKXP 8x18-8/1 I blue 01 LDPE 04
Material number: 56483 Packaging unit: 1000 Minimum order quantity: 1000 Availability: On stock |
Color: blue 01 Inner diameter (mm): 8.00 Inner length (mm): 18.00 Shank diam. (mm): 8.00 Availability: On stock | Material: LDPE 04 Type of part: Inner part |
